| TECHNICAL SPECIFICATIONS |
STH 450 S |
| | Minimum honing range | 40 mm | | Maximum honing range | 250 mm | | Maximum work piece height | 700 mm | | Maximum honing stroke | 450 mm | | Minimum distance between spindle and table | 300 mm | | Maximum distance between spindle and table | 1100 mm | | Distance from spindle center to column | 450 mm | | Spindle rotation speed | 0 ÷250 rpm | | Spindle movement speeds | 0 ÷16 m/1' | | Maximum longitudinal travel of table | 1400 mm | | Table dimensions | 600x1800 mm | | Hydraulic motor power | 1,5 kw AC motor | | Spindle rotation motor power | 2,2 kw AC motor | | Work head movement motor power | 0,37 kw AC motor | | Coolant unit motor power | 0,09 kw AC motor | | Table movement motor power | 0,40 kw servo motor | | Table fast movement speed | 2000 mm/1' | | Table manual feed with handwheel encoder | 0.1mm/div 1mm/div | | Table movement by ball screw system |
|
|
|
------
| ------
|
------
| ------
|
------
| ------
|
------
| ------
|
------
| ------
|
------
| ------
|
------
| ------
|
------
| ------
|
------
| ------
|
------
| ------
|
------
| ------
|
------
| ------
|
------
| ------
|
------
| ------
|
------
| ------
|
------
| ------
|
------
| ------
|
------
| ------
|
------
| ------
|
------
| ------
|
| CODE |
STANDARD EQUIPMENTS |
ADET / QUANTITY
|
|
STD 2034 |
P7 inch touch screen panel |
1
|
|
STD 2035 |
PLC system for touch screen panel and servo motor | 1
|
|
STD 2036 | Remote access device |
1
|
|
STD 2037 | X axis servo motor |
1
|
|
STD 2038 |
X axis handwheel encoder |
1
|
|
STD 2039 |
Automatic honing head (Ø 65x150 mm) | 1
|
|
STD 2040 |
Automatic honing head working flange | 1
|
|
STD 2041 |
Pair of parallel supports (140x590 mm) |
2
|
|
STD 2042 | Parallel supports clamping plate |
4
|
|
STD 2043 |
Workpiece rapid clamping fixtures |
2
|
|
STD 2044 | Hydraulic system |
1
|
|
STD 2045 |
Spot light |
1
|
|
STD 2046 |
Balancing nuts and rubbers |
6
|
|
STD 2047 |
Operating manual |
1
|
----
| ------ | ------
|
----
| ------ | ------
|
----
| ------ | ------
|
----
| ------ | ------
|
----
| ------ | ------
|
----
| ------ | ------
|
----
| ------ | ------
|
----
| ------ | ------
|
----
| ------ | ------
|
----
| ------ | ------
|
----
| ------ | ------
|
----
| ------ | ------
|
----
| ------ | ------
|
----
| ------ | ------
|
----
| ------ | ------
|
----
| ------ | ------
|
| CODE |
OPTIONAL EQUIPMENTS |
ADET / QUANTITY
|
|
SR 1675 |
Automatic honing head : Ø 65x150 mm (Honingtech product) |
1
|
SR 1676
|
Automatic honing head tool Ø 150x275 mm |
1
|
SR 1677
|
Automatic honing head : Ø 44x66 mm (Honingtech product) |
1
|
|
SR 1678 |
Automatic honing head working flange |
1
|
|
SR 1679 |
Setting-up fixture with automatic centering for cylinder liners clamping : Ø 60÷150 mm
|
1
|
|
SR 1680 |
Setting-up fixture with automatic centering for cylinder liners clamping : Ø 150÷300 mm |
1
|
|
SR 1681 |
Universal setting up fixture for “V” blocks (Single spindle) |
1
|
|
SR 1682 |
Spot light |
1
|
| |
|
-------
| ----- | ------
|
-------
| ----- | ------
|
-------
| ----- | ------
|
-------
| ----- | ------
|
-------
| ----- | ------
|
-------
| ----- | ------
|
-------
| ----- | ------
|
-------
| ----- | ------
|
-------
| ----- | ------
|
-------
| ----- | ------
|
|
DIMENSIONS
|
|
Length
|
2000 mm
|
|
Height
|
2060 mm
|
|
Width
|
1500 mm
|
|
DIMENSIONS WITH PACKING
|
|
Length
|
2150 mm
|
|
Height
|
2200 mm
|
|
Width
|
1650 mm
|
|
WEIGHTS
|
|
Without packing
|
1400 kg
|
|
With packing
|
1500 kg
|
